Home | Wood peeling chipper blades
Wood peeling chipper blades
Tungsten carbide Rotary lathe machinery blades
- Material :Tungsten carbide
- Product description: rotary lathe blade ,rotary peeling blade,rotary peeling knife
| Popular size of Veneer Rotary Knives/Peeling Knives (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 1270 | 180 | 16 | 80+/-2mm |
| 1397 | 197 | 16 | 100+/-2mm |
| 1400 | 180 | 16 | 80+/-2mm |
| 1500 | 180 | 16 | 80+/-2mm |
| 1700 | 197 | 16 | 100+/-2mm |
| 2750 | 180 | 18 | 80+/-2mm |
| 2760 | 200 | 16 | 100+/-2mm |
| 3300 | 220 | 16 | 100+/-2mm |
| 4040 | 235 | 20 | 100+/-2mm |
| 4200 | 220 | 16 | 100+/-2mm |
| Popular size of Slicer/Vertical Slicer knives (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 1190 | 140 | 16 | 60+/-2mm |
| 1200 | 130 | 13 | 60+/-2mm |
| 1200 | 185 | 20.5 | 80+/-2mm |
| 1500 | 185 | 20.5 | 80+/-2mm |
| 2750 | 190 | 19 | 100+/-2mm |
| 2750 | 240 | 15 | 100+/-2mm |
| 2850 | 200 | 20 | 100+/-2mm |
| 3300 | 220 | 22 | 100+/-2mm |
| 3500 | 200 | 24 | 100+/-2mm |
| 4200 | 240 | 20 | 100+/-2mm |
| Popular size of Wood Shear/Clipping Blades (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 675 | 115 | 10 | 50+/-2mm |
| 675 | 115 | 12 | 50+/-2mm |
| 1500 | 85 | 12.7 | 35+/-2mm |
| 2744 | 100 | 10 | 40+/-2mm |
| 2760 | 90 | 9 | 40+/-2mm |
| 2800 | 85 | 10 | 35+/-2mm |
| 2800 | 100 | 10 | 40+/-2mm |
| 2820 | 120 | 10 | 50+/-2mm |
| 2850 | 100 | 10 | 40+/-2mm |
| 3100 | 100 | 10 | 40+/-2mm |
| Popular size of Wood Pressure Bar (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 1500 | 80 | 12.7 | 35+/-2mm |
| 1500 | 80 | 13 | 35+/-2mm |
| 2700 | 62 | 14 | 25+/-2mm |
| 2750 | 80 | 13 | 35+/-2mm |
| 2750 | 62 | 45 | 25+/-2mm |
| 2760 | 70 | 40 | 35+/-2mm |
| 2795 | 68 | 14.8 | 35+/-2mm |
| 2810 | 50 | 12 | 20+/-2mm |
| 3290 | 47 | 12 | 20+/-2mm |
| 3340 | 65 | 18 | 30+/-2mm |
| Popular size of Wood Chipper Knives (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 780 | 220 | 20 | Solid |
| 665 | 220 | 20 | Solid |
| 850 | 220 | 20 | Solid |
| 875 | 220 | 20 | Solid |
| 600 | 180 | 20 | Solid |
| 669 | 290 | 25 | Solid |
| 258 | 75 | 6.5 | Solid |
| 482 | 110 | 14 | Solid |
| 880 | 180 | 16 | Solid |
| 665 | 220 | 20 | Solid |
| Popular size of Wood Planer Knives (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 310 | 25/30/35 | 3 | Solid |
| 410 | 25/30/35 | 3 | Solid |
| 510 | 25/30/35 | 3 | Solid |
| 610 | 25/30/35 | 3 | Solid |
| 1050 | 25/30/35 | 3 | Solid |
| 1300 | 25/30/35 | 3 | Solid |
| 460 | 38 | 6 | Solid |
| 610 | 38 | 6 | Solid |
| 82 | 29 | 3 | Solid |
| 110 | 29 | 3 | Solid |
| Popular size of Flaker knives/ Spur knives (mm) | |||
| Length | Width | Thickness | Inlay Size |
| 140 | 47 | 8 | Solid |
| 225 | 100 | 5 | Solid |
| 300 | 55 | 6 | Solid |
| 300 | 100 | 5 | Solid |
| 374 | 100 | 5 | Solid |
| 400 | 140 | 8 | Solid |
| 449 | 100 | 5 | Solid |
| 450 | 100 | 5 | Solid |
| 450 | 75 | 5 | Solid |
| 464 | 100 | 5 | Solid |
| 250 | 25 | 7.8 | Solid |
| 250 | 18 | 7.8 | Solid |
| 205 | 25 | 6 | Solid |
